Remote Annunciation

Edwards Signaling 8/6/2018
Remote Annunciation

Remote Annunciation

Kidde R-Series Annunciators are high-performance remote annunciators that provide status indication and common controls for Edwards Intelligent Addressable fire alarm systems. This family of annunciators offers LCD or LED annunciation as well as a graphic annunciator driver. Models are available with and without common controls.

Remote Annunciation

There are three Kidde R-Series annunciator models, plus an LED-based expander. Up to two expanders can be connected to any annun- ciator. The expander includes 24 pairs of LEDs that extend the capabilities of any of the annunciators.

All annunciator models include status LEDs and an internal buzzer. Two models have an LCD text display, and one has 16 pairs of LEDs for zone annunciation. LCD models feature a large back-lit, four by twenty character per line, super-twist liquid crystal display.

Edwards R-Series annunciators and expanders are mounted on a standard 4-inch square electrical box, using the included mounting ring. They can also be surface mounted in locking steel enclosures. Three different enclosures are available.

Remote Annunciation
Remote Annunciation

A keyswitch or locking enclosure are available for Kidde R-Series annunciator applications. The keyswitch enables or disables common controls. The key switch and locking enclosures limit access to the common controls to authorized personnel and may be required to meet  NFPA requirements. The common controls on Kidde E-RLCD-C can also be password protected.

Remote Annunciators

RLCD-R LCDtext annunciator without commoncontrols. Red. Data Sheet S85005-0128
E-RLCD LCDtext annunciator without commoncontrols. White. Data Sheet S85005-0128
RLCD-CR LCDtext annunciator with common controls. Red. Data Sheet S85005-0128
E-RLCD-C LCDtext annunciator with common controls. White. Data Sheet S85005-0128
RLED-CR 16-pair LEDzone annunciator withc ommon controls. Red. Data Sheet S85005-0128
E-RLED-C 16-pair LEDzone annunciator with common controls. White. Data Sheet S85005-0128

Remote Expanders

RLED24R 24-pair LEDzone expander withexpander cable andzone cardinsert. Red. Data Sheet S85005-0128
