232.25 Process Gauge, 0-2000 PSI, 6" Dial

$485.92 / EA
  • Manufacturer: WIKA
  • Product Family: Type 232.25
  • Pressure Range: Standard Pressure Range
  • Connection Size: 1/2"
  • Connection Location: Back Mount
  • Connection Type: MPT
  • Filled: Dry Case
  • Dial Size: 6"
  • Wetted Material: Stainless Steel
  • Case: Aluminum
  • Pressure Range (PSI/inHG/IN H2O): 2000 PSI
WIKA 232.25 Pressure Gauge with Hinged Ring, dry case, 6" dial, 0-2000 psig range, 316 SS wetted parts, 1/2" NPT lower back mount, black aluminum hinged ring case, 0.5% of span accuracy, solid-front safety case

Contact Our Gauge Experts

Need help selecting a pressure gauge? Contact our experts to answer questions.

Use our Gauge Finder Tool to search by specific attributes for your application needs.


  • Gauge Calibration Services
  • Gauge seal assembly and mounting
  • Diaphragm seal assembly and maintenance
  • Gauge liquid filling with various types of fills
  • Custom dial pressure measurement ranges
  • Gauge audits to insure proper functions
  • Vacuum gauge calibration and repair

Product Description

Featuring a solid-front aluminum safety case design with a hinged ring for easy access to the adjustable pointer, the WIKA 232.25 pressure gauge is supplied with three threaded bolts in the back of the case for panel mounting. The 232.25 pressure gauge features all 316 stainless steel wetted parts.

  • 316 stainless steel wetted parts
  • Black aluminum hinged-ring case
  • Solid-front, blowout back safety design
  • Adjustable pointer
  • Pressure ranges from 30" Hg vacuum to 20,000 psig

Dimension Drawing
