4363821 WIKA Mechanical Pressure Gauge

Request for Quote
  • Pressure Range (PSI/inHG/IN H2O): 0/5 PSI
  • Dial Size: 4.5"
  • Connection Size: 1/2 in. Threaded
  • Connection Location: Lower Mount
  • Accuracy: +/-2 Percent
  • Application: Chemical/Petrochemical, Corrosive Environment, Mining, Power Station, Process Industry
  • Dial Color: White
  • Dial Material: Aluminum
  • Display Type: Dial
  • Enclosure Rating: IP54, NEMA 3
  • Full-Scale Accuracy: +/-2 Percent
  • Material: Black Fiberglass Reinforced Thermoplastic
  • Mid-Scale Accuracy: +/-1 Percent
  • Pointer Color: Black
  • Pointer Material: Aluminum
  • Pointer Type: Adjustable
  • Sensor Element: 316L Stainless Steel Capsule
  • Temperature Rating: -4 to 140 Deg F (Ambient), 212 Deg F (Medium)

WIKA Type 632.34 Mechanical Pressure Gauge, 1/2" NPT, 0/5 PSI, 4.5" White Aluminum Dial, +/-2/1/2% Accuracy, Black Fiberglass Reinforced Thermoplastic Case, Black Aluminum Adjustable Pointer, 316L Stainless Steel Capsule, Lower, Low Pressure Capsule, Mechanical Pressure Gauge.

Browse All WIKA Products


Contact Our Process Control Experts

Contact our experts to answer questions or help you with your application needs.


  • Distribution of components services
  • On-site inventory management
  • Factory Automation Services
  • Product expediting
  • Product obsolescence notifications and replacements
  • Kitting and packaging
  • Custom labeling

Product Description

Mechanical Pressure Gauge; Pressure Gauge Type Low Pressure Capsule; Maximum Pressure 0/5 PSI; Display Type Dial; Enclosure NEMA 3, IP54; Enclosure Material Black Fiberglass Reinforced Thermoplastic; End Connection 1/2 Inch Threaded; Connection Location Lower; Sensor Element 316L Stainless Steel Capsule; Dial Diameter 4.5 Inch; Dial Material Aluminum; Dial Color White; Pointer Type Adjustable; Pointer Material Aluminum; Pointer Color Black; Temperature Rating -4 to 140 Deg F (Ambient), 212 Deg F (Medium); Full Scale Accuracy +/-2 Percent; Mid Scale Accuracy +/-1 Percent; Accuracy +/-2 Percent; Application Chemical/Petrochemical, Corrosive Environment, Mining, Power Station, Process Industry; Dial Letter Color Black; Includes Stainless Steel Movement, Turret-Style Case with Built-In Rear Flange Lug, Clear Acrylic Window with Buna-N Gasket
