451279BS04LXNHSG400# Ashcroft Pressure Gauge
- Dial Size: 4-1/2"
- Connection Location: Lower Mount
- Dial Material: Aluminum
- Display Type: Dial
- Full-Scale Accuracy: +/-0.5 Percent
- Max. Pressure: 400 PSI
- Min. Pressure: 0 PSI
- Mounting Type: Stem/Surface
- Pointer Material: Aluminum
- Pointer Type: Micrometer Adjustable
- Sensor Element: AISI 4130 Steel Bourdon Tube/AISI 1019 Steel Socket
- Temperature Rating: -20 to 200 Deg F (Ambient), -20 to 250 Deg F (Process), -40 to 250 Deg F (Storage)
- Enclosure Material: Phenolic
- End Connection: 1/2" Male Threaded
Ashcroft 1279 Pressure Gauge, 1/2" MPT, 0 to 400 PSI, +/-0.5% Accuracy, 4-1/2" Aluminum Dial, Micrometer Adjustable Pointer, AISI 4130 Steel Bourdon Tube/AISI 1019 Steel Socket, Phenolic Case, Non-Stick Coated 400 Stainless Steel Rotary/Adjustable Movement, Polycarbonate Threaded Ring, Dry, Lower, Pressure Relief Back Solid Front, Single Scale, Pressure Gauge with Stainless Steel Tag and Safety Glass Window.
Pressure Gauge; Pressure Gauge Type Pressure Relief Back Solid Front, Single Scale; Minimum Pressure 0 PSI; Maximum Pressure 400 PSI; Mounting Type Stem/Surface; Display Type Dial; Enclosure Material Phenolic; End Connection 1/2 Inch Male Threaded; Connection Location Lower; Sensor Element AISI 4130 Steel Bourdon Tube/AISI 1019 Steel Socket; Dial Diameter 4-1/2 Inch; Dial Material Aluminum; Pointer Type Micrometer Adjustable; Pointer Material Aluminum; Filler Material None; Temperature Rating -20 to 200 Deg F (Ambient), -20 to 250 Deg F (Process), -40 to 250 Deg F (Storage); Full Scale Accuracy +/-0.5 Percent; Application Refinery, Chemical, Petrochemical Plant and Offshore Oil Rig, Water and Wastewater Pressure Control, Pulp and Paper, Mining and Metal, Equipment Skid, Specialized OEM Equipment, Cryogenic; Case Design Dry; Dial Figure Color Black; Dial Baground White; Threaded Ring Material Polycarbonate; Pressure Relief Back Material Polycarbonate; Window Material Safety Glass; Moment Details Non-Stick Coated 400 Stainless Steel Rotary/Adjustable; Includes Stainless Steel Tag; Applicable Standard CRN, UL 94 V-0, ASME B40.100 Grade 2AFeatures/Benefits
Solid-front case design for safetySeries Information
The Ashcroft® 1279 Duragauge® pressure gauge provides dependability, safety and performance. Used throughout the served markets, its manufacture is continuously monitored to assure uncompromising standards and material integrity. An ideal choice for satisfying most applications and installation requirements.
