9747473 WIKA 611.10 Capsule Gauge, 0-100 H2O, 2.5" Dial

9747473
$52.51 / Each
  • Pressure Range Type: Low Pressure Range - IN/H2O, Oz H2O
  • Pressure Range (PSI/inHG/IN H2O): 100 IN H2O VAC
  • Dial Size: 2-1/2"
  • Connection Size: 1/4"
  • Connection Location: Lower Mount
  • Connection Type: MPT
  • Filled: Dry Case
  • Wetted Material: Brass
  • Case: Steel

WIKA 611.10 Low Pressure Process Gauge, dry case, 2-1/2" dial, 0-100" (0-2500mm) H2O vacuum range, Copper Alloy (Brass) wetted parts, 1/4" NPT lower mount, black-painted steel case, 1.5% of span accuracy, "H2O/mmH2O dual scale

Browse All Model 611.10 & 631.10 Products

Browse All WIKA Products

QTY

Contact Our Gauge Experts

Need help selecting a pressure gauge? Contact our experts to answer questions.

Use our Gauge Finder Tool to search by specific attributes for your application needs.

Services

  • Gauge Calibration Services
  • Gauge seal assembly and mounting
  • Diaphragm seal assembly and maintenance
  • Gauge liquid filling with various types of fills
  • Custom dial pressure measurement ranges
  • Gauge audits to insure proper functions
  • Vacuum gauge calibration and repair

Product Description

Extremely sensitive and highly accurate, the WIKA 611.10 low pressure process gauge is designed to measure pressure and vacuum of gaseous media. The 611.10 gauge has a recalibration screw located on the dial for re-zeroing the pointer.

  • Copper alloy wetted parts
  • Black-painted steel case
  • Recalibration screw on dial
  • Ranges from 30" H2O vacuum to 10 psig
  • Available in 2" and 2-1/2" sizes

Dimension Drawing
