UE Precision Sensors Gauge Pressure Switch

P36W Series
Request for Quote
  • Manufacturer: UE Precision Sensors
  • Product Family: P36W Series
  • Product Type: Gauge Pressure Switch

The P36W series high purity gauge pressure switches offer accurate and repeatable switching for monitor/control and alarm/shut down protection. These units designed specifically for high purity gas applications, are used to measure gauge pressure (above atmosphere).

FEATURES:
  • Tamper proof (factory) setting
  • Welded construction
  • Negative-rate belleville spring design for longer life, accuracy and repeatability
  • RoHS Compliant
QTY

Contact Our Process Control Experts

Contact our experts to answer questions or help you with your application needs.

Services

  • Distribution of components services
  • On-site inventory management
  • Factory Automation Services
  • Product expediting
  • Product obsolescence notifications and replacements
  • Kitting and packaging
  • Custom labeling

Specifications

Approval UL, CE
Available Settings 2.5 to 30 PSIG
Deadband 1 psi + 6% of Setting
Electrical Connections Crimp Type Connectors, Free Leads
Finish 5 Ra
Internal Volume 1.06 CC
Media Connections 1/4" End Seal Type, 1.125" "C" Seal
Min. Operating Life 1 Million Cycles
Operating Temp. Range 0 to 130 F Deg.
Proof Pressure 0 psia - 25 psig
Repeatability +/- 0.3 psi + 2% of Setting
Warranty 36 Months
Wetted Materials 316L per F20

Dimensional Drawing

UE Precision Sensors P36W Series Dimensions

Ordering Guide

UE Precision Sensors W Series Ordering Guide
