WE-502FB-RYGBC Patlite WE Series 37.5mm LED Signal Tower

$435.00 / Each
  • Lighting Option: Continuous or Flashing
  • Tiers: 5
  • Refine Search: Audible & Visible Signals
  • Product Type: Signal Towers/Buzzers

Patlite, WE Series 37.5mm LED Signal Tower, 5 tier, top to bottom: Red, Amber, Green, Blue, Clear, continuous lighting or flashing, with buzzer, 24V AC/DC (50/60Hz), dust and water resistant, chrome plated body.

Browse All WE Products

Browse All Patlite Products


Contact Our Motion Control & Automation Experts

Contact our experts to answer questions or help you with your application needs.


  • Control & Automation Engineering
  • Control Panel Services
  • Control System Design
  • Machine Vision Services
  • Maint/Repair Service Contracts
  • PLC Services
  • Rexroth Indramat Repair Center

Product Description

The WE Series features an ultra slim half-moon shaped LED Signal Tower offering seamless integration with most equipment

  • Clear vertical-cut lens for enhanced illumination over a wide perspective.
  • Optional built-in audible alarm (FB type) with an output of 90dB (at 1m).
  • Chrome-plated body.
  • Installation: vertical or horizontal.
  • Body color selections: chrome plated or ivory white.
  • Lens is made of superior impact and heat resistant polycarbonate resin for superior durability and enhanced illumination.
  • NPN and PNP Compatible for direct connection to a PLC (24V DC ONLY)
  • Two lighting patterns: flashing and continuous lighting.
  • Dust and water resistance rating of IP65 (except for FB type: IP54).
  • Available colors: Red, Amber, Green, and Blue.
  • CE mark and conforms to the requirements for the EC directive.
  • UL Recognized Component (File No. E215660).

Dimension Drawing
