AC-5VLV-0005 Aventics 2x3/2-directional Valve, Series AV03

Request for Quote
  • Product Type: Directional Valve

AVENTICS™ 2x3/2-directional valve, Series AV03, with spring return, NC, 24 VDC

Browse All Aventics Products


Contact Our Motion Control & Automation Experts

Contact our experts to answer questions or help you with your application needs.


  • Control & Automation Engineering
  • Control Panel Services
  • Control System Design
  • Machine Vision Services
  • Maint/Repair Service Contracts
  • PLC Services
  • Rexroth Indramat Repair Center

Related Products & Accessories

Valin Ventura Centura Manifold Replacement
AC-150-2444 Customer Part #:
Request for Quote

Product Description

The AVENTICS™ Series AV03 provide a reliable basis for both compact handling systems and complex automation solutions. Within machine safety the Series AV03 offers intelligent solutions that significantly reduce your effort in creating a safe design. With the integration of the fieldbus and I/O-modules of the Series AES, also all requirements for distributed control are available. The Series AV03 is easy to configure, easy to use and easy to extend as well as futureproof thanks to the option of IIoT integration.

  • Function: NC/NC
  • Activation: Electrically
  • Flow L/M: 300 l/min
  • DC operating voltage: 24 V
  • Max Working Pressure: 10 bar
  • Housing: Polyamide fiber-glass reinforced
  • Sealing Material: Acrylonitrile butadiene rubber
  • Modes of Protection: Protected against polarity reversal
  • Actuating control: double solenoid
  • Return type: With spring return
  • Switching principle: 2x3/2
  • Protection class: IP65
  • LED color: Yellow
  • Min to Max Ambient temperature: -10 °C - 60 °C
  • Manual override: without detent
  • Working pressure min.: -.9 bar
  • Modular concept
  • Intelligent solutions for machine safety demands
  • Suits compact handling systems and complex automation solutions
  • High connectivity through Multipol or Fieldbus connection
  • Integration of a wide range of I/O-modules
  • Light weight
  • Low energy consumption
  • Covers requirements of global automation technology, even under UL specifications and in ATEX-areas
  • The Series AV03 offers the possibility of assembly into cabinets
  • Easy and flexible custom specific configurations via online configurator

Dimension Drawing

valin ac-5vlv-0005 2x 3/2 directional valve series av03 drawing
